Why is the Quad Pod K50 & K65 range of mobile floodlights so popular?
About Our Quad Pod K50 & K65 Industrial Mobile Floodlights
The special demands of the construction, hire, rail and utilities sectors require unique solutions from equipment manufacturers, none more so than for mobile lighting equipment.
The potential applications for mobile lighting towers are wide ranging and diverse. From construction sites to outdoor sporting events, each application has its own specific requirements regarding the type of light projection required, power sources available, access to the site and placement of the towers.
The range includes 2 models. The K50 which extends to 5M height and the K65 which extends to 6.5M height. Both models can be fitted with either 4 or 6 High power 200W LED light heads.
5 metre mast height
3 mast sections
4 or 6 light heads
200W LED lights
6.5 metre mast height
4 mast sections
4 or 6 light heads
200W LED lights
Not Sure How Many Mobile Floodlights You’ll Need?
Tell us a little bit about your lighting area and we’ll create a custom lighting diagram. It will show you how many lights you’ll need to cover the area.
Quad Pod Light Effects
The Quad Pod’s Flexible Adjustable LED Light heads can be positioned to create the desired light effect from a 180 degree directional light to a full 360 degree area light.
180 Degree Light
360 Degree Light
|Product Code||Mast Height||Number Of Heads||Technology||Weight||Closed Dimensions||Open Dimensions|
|K50/MK3-LED4-ROUND||5m||4||LED||215Kg||1030 x 850 x 1970mm||2370 x 3100 x 5380mm|
|K50/MK3-LED6-ROUND||5m||6||LED||241Kg||1030 x 850 x 1970mm||2370 x 3100 x 5380mm|
|K65/MK3-LED4-ROUND||6.5m||4||LED||234Kg||1030 x 850 x 1970mm||2370 x 3100 x 6890mm|
|K65/MK3-LED6-ROUND||6.5m||6||LED||268Kg||1030 x 850 x 1970mm||2370 x 3100 x 6890mm|
The Quad Pod portable lighting solution can be powered by:
- AC mains power supply (110V – 250V AC)
- Petrol or diesel generators
Extension leads are available in a variety of lengths to meet customer requirements.
Two standard wheel options are offered to provide the maximum stability, optimum handling and minimum ground impact on a range of surfaces:
- Low profile wheels / tyres – particularly suitable for hard / dry surfaces
- Low pressure pneumatic wheels / tyres – particularly suitable for grassed or uneven surfaces and for use in wet conditions
More About Our Mobile Floodlights
Many applications including outdoor events take place on surfaces which must be protected from damage. Vehicle access may be restricted or prohibited meaning that traditional solutions including road towable lighting towers cannot be used.
Manufactured by Ritelite in the UK, the K50 and K65 Quad Pod Mobile Lighting Towers are powerful, flexible and highly mobile lighting towers which can be used in just about any application.
Two models are currently available: the K50 with a working height of 5m and the K65 with 6.5m. Both models are fitted with high power 200W energy saving LED light heads which can be configured to provide an optimised light output according to specific user applications. The individual light heads can be adjusted to enable to Quad Pod to supply light in a 180 degree direction to floodlight an area or in a 360 degree direction to light a whole area. This enables users to adjust the light differently depending on the application.
The K50 & K65 mobile floodlights feature a rapid one person deployment system, reducing handling and set-up / break-down times to a minimum. All models can be deployed by one person in less than 2 minutes. The innovative and compact design makes the units straightforward to handle whilst also minimizing space claim for storage and transport.
In rough terrain applications, where access to site is restricted, or prevention of ground damage is critical, the built-in folding wheels with optional low pressure tyres allow the K50 & K65 Quad pod mobile lighting towers to be moved into position by one person. The Flexible power options enable the K50 & K65 to be used almost anywhere as they can be powered by either a generator or mains power. Using only max 1200W per mobile tower they are economic to run and on mains power are silent and fume free.
